22 November 1998
Source:
http://csrc.nist.gov/publications/history/myer80.pdf
(3,731K)
From CSRC/NIST's collection
of Early
Computer Security Papers, Part I
See related The Inevitability of
Failure: The Flawed Assumption of Security in Modern Computing Environments
(TOS Unit, National Security Agency, November 1998)
NAVAL POSTGRADUATE SCHOOL
Monterey, California
THESIS
SUBVERSION:
THE NEGLECTED ASPECT OF
COMPUTER SECURITY
by
Philip A. Myers
June, 1980
Thesis Advisor: Roger R. Schell |
Approved for public release; distribution unlimited
DD FORM 1473, REPORT DOCUMENTATION PAGES, 2 pp. Omitted
SECURITY CLASSIFICATION OF THE TWO PAGES: Unclassified
Approved for public release; distribution unlimited
Subversion:
The Neglected Aspect of Computer Security
by Philip A. Myers
Lieutenant, United States Navy
B.S.. North Carolina State University, 1973
Submitted in Partial Fulfillment of the
Requirements for the Degree of
MASTER OF SCIENCE IN COMPUTER SCIENCE
from the
NAVAL POSTGRADUATE SCHOOL
June, 1980
Author:
[Signature]
Approved by:
[Signature] Thesis Advisor
[Signature] Second Reader
[Signature] Chairman, Department of Computer Science
[Signature] Dean of Information and Policy Sciences
This thesis distinguishes three methods of attacking internal protection
mechanisms of computers: inadvertent disclosure, penetration, and subversion.
Subversion is shown to be the most attractive to the serious attacker. Subversion
is characterized by three phases of operations: the inserting of trap doors
and Trojan horses, the exercising of them, and the retrieval of the resultant
unauthorized information. Insertion occurs over the entire life cycle of
the system from the system design phase to the production phase. This thesis
clarifies the high risk of using computer systems, particularly so-called
"trusted" subsystems for the protection of sensitive information. This leads
to a basis for countermeasures based on the lifetime protection of security
related system components combined with the application of adequate technology
as exemplified in the security kernel concept.
[pp. 5-8]
I. INTRODUCTION
II. UNDERSTANDING THE COMPUTER SECURITY PROBLEM
A. LACK OF COHERENT POLICY
B. INADEQUATE INTERNAL MECHANISMS
C. FALSE ASSURANCES
1. Reliance on "Trusted" Subsystems
2. No Lifetime protection
D. CHAPTER SUMMARY
III. METHODS OF ATTACKING INTERNAL SYSTEM CONTROLS
A. INADVERTENT DISCLOSURES
B. PENETRATION
1. Penetration Environment
2. The Penetrator
C. SUBVERSION
1. Subversion Over a System Life Cycle
2. Skills Required
3. The Artifice
a. Trap Doors
b. Trojan Horses
D. CHAPTER SUMMARY
IV. METHODOLOGIES OF SUBVERSION
A. GENERAL CONSIDERATIONS
1. Safe Computing Sites
2. Scope of Operations
3. Desirable Traits in Artifices
a. Software trap doors
(1) Compactness
(2) Revision Independence
(3) Installation Independence
(4) Untraceable
(5) Uniquely Triggerable
(6) Adaptability
b. Trojan horses
(1) Directed Lure
(2) CompatibiLity of Functions
c. Hardware Mechanisms
4. Obscuring Artifices
a. Modifying Object Code
b. Abusing Software Engineering Practices
c. Using Assembler Languages
d. Strategic Placement
e. Using Confinement Channels
f. Hardware Obscuring
B. INSERTING ARTIFICES OVER THE LIFE CYCLE OF A COMPUTER SYSTEM
1. Design Phase
a. Operating System Software
(1) Password Procedures
(2) Audit Procedures
(3) Confinement Channels
(4) Backward Compatible Features
b. Other Software Design Choices
c. Hardware Alternatives
(1) Central Processors
(2) Peripherals
2. Implementation Phase
a. Coding and Testing
b. Hardware Assembly and Checkout
3. Distribution Phase
4. Installation Phase
5. Production Phase
6. Summary
C. EXERCISING ARTIFICES
1. Activating Artifices
a. Software Activation
(1) Trojan Horses
(2) Trap doors
b. Hardware Activation
2. Techniques of Exploitation
a. Breaking Out of a Subsystem
b. NPS Penetration Case
c. Using Emitters
d. Memory Residue
e. Using Confinement Channels
f. Affecting System Performance
D. RETRIEVING INFORMATION
1. Retrieving Files
2. Retrieving with Hardware Devices
E. CHAPTER SUMMARY
V. MINIMIZING THE RISK OF SUBVERSION
A. RESTRICTING INSERTION OPPORTUNITIES
1. Lifetime Protection
2. Appropriate Protection Policies
B. RESTRICTING EXERCISING OPPORTUNITIES
C. RESTRICTING THE RETRIEVAL OF INFORMATION
1. Delineating the Internal Security Perimeter
2. Security Kernel Concept
D. CHAPTER SUMMARY
VI. CONCLUSIONS AND RECOMMENDATIONS
LIST OF REFERENCES
INITIAL DISTRIBUTION LIST
I would like to thank my thesis advisor Lt. Col. Roger R. Schell, USAF, for
the many hours he has spent in helping me to understand the relevant issues
involved in computer security.
[pp. 10-12]
To use internal mechanisms within a computer system to protect sensitive
information without demonstrable assurances as to the origins and effectiveness
of the system components is contrary to a sound security practice. Use of
allegedly "secure" or "trusted" subsystems based on operating systems that
are fundamentally unsecurable is likewise unsound. Yet these two conditions
can, and do, exist within the constraints of current ADP security policy
and practice. As a result, supposedly "secure" computer systems present a
major risk of compromise for sensitive information.
These conditions can exist because there is a basic lack of understanding
as to the possible vulnerabilities of computer systems. In particular, subversion
is one area that is widely neglected. The subversion of a computer system
is the covert and methodical undermining of internal and external controls
over a systems lifetime to allow unauthorized and undetected access to system
resources and/or information.
This thesis details the methodologies involved in subversion, and how they
can be used to attack a computer system. It is essential that all personnel
involved in ADP security understand subversion and how it works. Without
this understanding, effective policies and countermeasures cannot be devised
and implemented.
The increased use of "off the shelf" ADP systems and programs can help realize
significant economies in procurement costs, but there are significant dangers
as well. These dangers come about because there is a pressing need for computer
systems to "securely support multiple users of differing degrees of
trustworthiness simultaneously handling data of differing degrees of
sensitivity." This is known as the classical computer security problem [1].
It is a problem because no known commercially available system can be proven
to offer the secure support required.
Present technology such as that found in the Security Kernel [2] concept
point the way to a solution to the computer security problem. But no technology
will assure secure computer systems unless proper safeguards are implemented
to protect this technology from subversion.
To understand what is involved in the subversion of computer systems one
must first be acquainted with the background of the computer security problem
(Chapter II). The problem is not merely a historical one. There is currently
no clear policy as to what role computer systems are to play in the protection
of information. As a result, systems are plagued with inadequate internal
protection mechanisms whose effectiveness cannot be assured. Chapters III
and IV deal with how these inadequacies can be exploited through subversion.
Finally Chapter V discusses how the risk of subversion can be minimized.
[pp. 13-26]
The computer security problem has grown with the computer industry. When
the entire system was dedicated to a single user, protection consisted of
the user simply picking up his tapes and cards and clearing CPU core when
the job was finished. Basically the user had complete control over his processing
environment, including his data and programs. After a few years users began
demanding better utilization of the resources. The response to this demand
for more efficiency gave birth to multiplexing techniques, resource sharing
operating systems, multiprogramming and various other techniques of the age.
The user suddenly found not only a lack of control over the processing
environment but a lack of control over the protection of his data and programs
as well. Gat [3] indicates:
With the appearance of multiplexing techniques there arose the problem of
defending independent software structures from each other, as these were
often implemented on the same physical resource. Thus, multiprogramming operating
systems enforce some sort of isolation between simultaneously executing
processes.
Since efficiency was the main consideration in computer systems design, criteria
limited the "defending" and "isolation" to the containment of accidents and
errors [2].
Organizations desiring to utilize the increased capacities of resource sharing
systems demanded assurances that sensitive and nonsensitive information could
be processed concurrently. Bisbey [25] comments:
Responding to customer pressure, the systems manufacturers at first claimed
that hardware and software mechanisms supporting resource sharing would also
(with perhaps minor alterations) provide sufficient protection and isolation
to permit multiprogramming of sensitive and nonsensitive programs and data.
This claim was soon discounted in the early 1970s with the introduction of
several penetration tiger teams that were specifically tasked to test the
protection offered by several major operating systems. Even those systems
that underwent "retrofitting" to correct known implementation errors and
design oversights were penetrated with only moderate amounts of energy [1].
Evidence as recent as 1978 indicates that current operating systems for which
the major vendors have "conscientiously and competently attempted to improve
security" have been successfully penetrated [1].
Finally, as a crowning blow to the state of current computer systems, a Consensus
Report published in the proceedings of the 1979 National Computer Conference
[1] states:
It is a fact, demonstrable by any of several studies, that no existing
commercially-produced computer system can be counted upon to protect any
of its moderately knowledgeable users from having complete and undetectable
access to any information in the system, no matter what kinds of so-called
security features or mechanisms have been built into the system.
Harrison, Ruzzo, and Ullman in their paper "Protection in Operating Systems"
[4] provide conclusive proof that there is no algorithm that can prove an
arbitrary protection system (such as an operating system) safe. This means
it cannot be proven that an arbitrary operating system can withhold unauthorized
information from malicious users. This is because a system may not be (and
usually is not) designed in a manner that its safety can be precisely determined.
However, for a properly designed system the safety question could be decided.
But, the constraints placed on these "model" systems are too severe to prove
practical for the evaluation of current operating systems. In particular,
systems designed using the security kernel technology [3] can be definitively
evaluated for security. This technology will be briefly discussed in Chapter
V.
It has been said that understanding the computer security problem requires
close attention to three subjects: policy, mechanisms, and assurance [1].
It is essential to understand all aspects of the problem. Therefore, a brief
discussion of each area is offered.
A. LACK OF COHERENT POLICY
In general, a security policy defines what is meant by "secure" [5]. The
sources of this policy are laws and regulations that outline how information
is to be handled. The computer industry in general, both users and vendors,
have not reached a consensus as to what would constitute a coherent approach
to computer security policy. The Consensus Report [1] indicates:
This passive attitude on both sides tends to mask the general nature of the
security problem because the more knowledgeable security users demand solutions
to their unique problems, solutions that might not become standard parts
of a product line.
DOD fairs better in having a more specific policy as to the handling of sensitive
information in general. This policy involves a non-discretionary (or mandatory)
access control and within these constraints a discretionary control.
When information is given a formal security classification, it is forbidden
without explicit administrative declassification or downgrading to allow
someone to have access to information of higher classification than he is
cleared for, i.e., the holder of classified information has no discretionary
authority in this respect concerning who he can share it with. This rule
is an example of a mandatory access control policy [1].
Within the mandatory constraints there exists a discretionary policy that
allows the creator of the information discretion over access to the information
by other cleared personnel. This is the concept of "need to know." A person
must have the clearance (mandatory) and a need to know (discretionary) before
access to information is granted.
However in the area of sensitive information as it relates to the computer,
guidelines, such as those outlined above, are less clear. Policy does not
clearly discriminate between a computer providing only computation and one
providing both computation and protection [6].
In a simple computation environment, protection or security is enforced by
physical means external to the computer (fences, guards, etc.) as in a
"dedicated" mode of operation. In this mode, all users system are cleared
for the highest level of information contained in the system (i.e. it is
dedicated to processing at a given security level). All users, equipment,
and information reside within this protective boundary or "security perimeter."
Everything within the security perimeter is considered benign. The computer
system is not expected to seriously "defend" information from any of its
users because they are considered non-malicious by virtue of their security
clearances.
In the other environment (called the multilevel security mode) the computer
not only provides computation but must internally provide mechanisms that
distinguish levels of information and user authorization [6]. This is because
not all users of the system are cleared for the highest level of information
contained in the system. Here, the computer system must protect the information
from the uncleared (and possibly malicious) user. In effect, the computer
system must become part of the security perimeter. The internal protection
mechanisms (whatever they may be) must "assume the role" of the guards, fences,
etc. that are indicative of the external security perimeter. Policy (which
defines what is meant by "secure") must be clearly translated into terms
that can be implemented on a computer. Unless a specific policy is required
to be implemented on a computer system in a VERIFIABLE manner, there would
be no way one could determine if the computer system was EFFECTIVE in enforcing
the given policy.
B. INADEQUATE INTERNAL MECHANISMS
The baseline documents within DOD for ADP security are DOD Directive 5200.28
"Security Requirements for ADP Systems" [7] and its associated Manual DOD
5200.28M "The ADP Security Manual" [8]. The Directive states that "techniques
and procedures which can be used to secure and evaluate resource-sharing
ADP systems" are contained in the ADP Security Manual. Therefore, it is
instructive to specifically address the Manual.
Since the central issue of a multilevel security system concerns the use
of internal protection mechanisms to enforce protection of information, it
is important to understand what these mechanisms are.
The following are selected excerpts from the Manual that illustrate the
officially annunciated role of internal software mechanisms:
4-300 General
The user and master modes of ADP Systems operation shall be separated so
that a program operating in a user mode is prevented from performing control
functions.
4-301 O/S Controls
The O/S shall contain controls which provide the user with all material to
which he is authorized access, but no more.
4-305 Other Fundamental Features
Unauthorized attempts to change, circumvent, or otherwise violate these features
should be detectable and reported.... In addition the incident shall be recorded
in the audit log....
a. Memory/Storage protection - The operating system shall protect the security
of the ADP system by controlling:
1. Resource allocation (including primary and auxiliary memory);
2. Memory access outside of assigned areas; and
3. The execution of master (supervisory) mode instructions which could adversely
affect the security of the O/S.
b. ...
c. Access Controls - Access to material stored within the ADP System shall
be controlled by the ADP system security officer, ... or by automatic processes
operating under separate and specific controls within the O/S established
through hardware, software, and procedural safeguards approved by the ADP
System security officer.
d. ... e. ...
f. User identification - Where needed to assure control of access and individual
accountability, each user or specific group of users shall be identified
to the ADP system by appropriate administrative or hardware/ software measures.
Such identification measures must be in sufficient detail to enable the ADP
system to provide the user only that material which he is authorized.
These seem to be reasonable requirements to ask of a multilevel security
system. The problem is that there is no way that these requirements can be
proven effective. They can only be proven ineffective. This is evident in
the ADP Security Manual's ad-hoc method of Security Testing and Evaluation
(ST&E). An evaluation is defined in paragraph 1-213 of the manual:
The evaluator's report to the Designated Approving Authority describing the
investigative and test procedures used in the analysis of the ADP System
security features with a description and results of tests used to support
or refute specific system weaknesses that would permit the acquisition of
identifiable classified material from secure or protected data files.
Verification is defined in paragraph 1-225:
The successful testing and documentation of actual on-line system penetration
or attempts to penetrate the system in support or in contradiction of assumptions
developed during system review and analysis which are to be included in the
Evaluation report.
The above methodology is fundamentally flawed. Recall from mathematics that
it is sufficient to disprove a proposition (e.g., that a system is secure)
by allowing only one example where the proposition is false (e.g., a successful
penetration). It is not sufficient to prove the proposition by offering an
example where the proposition appears to hold (e.g., unsuccessful penetration
attempt). The best position to take concerning these methods is stated by
Schell [6]:
Do not trust security to technology unless that technology is demonstrably
trustworthy, and the absence of demonstrated compromise is NOT a demonstration
of security.
It is imperative that any mechanism that will be required to aid in the securing
of a computer system be constructed in such a way that it can, in fact, be
verified effective.
C. FALSE ASSURANCES
False assurances concerning the reliability of computer systems to effectively
protect information come about because people in positions of responsibility
do not understand that a "technical computer security" problem exists.
... government agencies, as well as private industry, continue to issue purchase
requests containing sections labeled "security requirements," which are mostly
lists of features and mechanisms, in the apparent belief they will obtain
something useful [1].
The previous section's discussion on policy illustrated how the reliance
on "features and mechanisms" without demanding demonstrable effectiveness
assurances.
No self respecting computer system salesman is going to admit that his products
cannot provide the effective protection that an application demands. No malicious
intent is implied by this statement, but the salesman is no more aware of
the true nature of the computer security problem than the customer who
unknowingly demands the ineffective "features and mechanisms" in a procurement
specification. The Consensus Report [1] demonstrates this lack of understanding:
... even if government procurement specifications were tightened to ask for
the kind of security we believe possible with the current state of the art,
fewer than fifty people in the country would understand the true implications
of what is being asked for, and those fifty are concentrated in less than
a half-dozen organizations, none of them in the main stream development
organizations of the major mainframe vendors. This is partly because at the
moment most efforts of vendors relating to security are concentrating on
the mechanisms part of the security problem, with very little attention to
the "assurance" part.
1. Reliance on "Trusted" Subsystems
A subsystem can be viewed as any computing environment that restricts the
users functions to a subset of the host computer's functional capabilities.
An example of this is a transaction data management system. The user is bound
to a restricted "menu" of functions that allow him to carry out only his
required tasks. For instance, a data entry clerk in such a subsystem has
no need to write programs, so this capability is not part of the clerk's
menu. The general feeling about subsystems is that by restricting the users
capabilities, he will be denied the tools he needs to perform malicious
activities.
Alleged "secure" or "trusted" subsystems are presently being developed
within DOD as a means of coping with the computer security problem:
Given an untrusted operating system, this approach employs the use of a trusted
transaction data management system or other trusted special-purpose subsystem
in concert with facility and procedural constraints that limit the population
of users to the trusted subsystem. (Only trusted users are allowed access
to any parts of the system outside of the trusted subsystem.) This solution
combines trusted software (but not the operating system itself) and trusted
procedures, and is an expedient until completely trusted operating systems
are more widely available. Secure subsystems development for the DOD in limited
transaction applications is currently underway [1].
Unfortunately one cannot exclude the operating system from the "solution"
as proposed in the above. All subsystems are "built" upon an underlying operating
system. The operating system must therefore be considered as an integral
part of the trusted subsystem.
Ample discussion has already been offered as to the unreliability of current
operating systems. A subsystem, when viewed from the aspect of the underlying
operating system, is nothing more than another application program. If there
are exploitable flaws in the underlying operating system that can be used
to exploit the system without the subsystem, then these same flaws can be
used to exploit it with the subsystem. Chapter IV demonstrates how this can
be done. Reliance must not be put on a "trusted" subsystem unless the foundation
on which it is built is solid and trustworthy.
2. No Lifetime Protection
There is no explicit Security Testing and Evaluation (ST&E) criteria
in DOD guidelines that takes into account the history of system components.
Using computer systems with uncertifiable backgrounds, particularly in multilevel
security mode applications, can prove particularly disastrous. The main thrust
of this thesis is concerned with just such issues. The lifetime of a computer
system is not just the operational lifetime, i.e., when it comes under the
control of an ADP security officer, but is from "conception until death."
This includes the design, implementation, distribution, installation, and
production phases of a computer system.
It is not sufficient to know that a given computer system and its associated
software are standard "off the shelf" versions of company XYZ's product line.
Without specific assurances concerning the protective measures that have
been afforded system components or the trustworthiness of development personnel,
there is no way that an effective evaluation can occur. If at some time prior
to the user taking control of a system, malicious elements have access to
system components, it would be virtually impossible to determine what
modifications to invalidate security controls were made. This lack of protection
is one of the fundamental reasons why the subversion of computer systems
can be so effective. Later chapters will amplify this concept.
It has been proposed [1, 9] that current operating systems be evaluated as
to their security attributes. The result of this evaluation would yield an
"approved products list." The resulting "grade" that a system would receive
would supposedly determine its relative ability to protect information. There
is a problem in that this criteria does not substantially address whether
or not the security related components (hardware and software) have received
the proper lifetime protection from malicious elements. Unless this vital
factor has been taken into account, any "approved products list" would prove
meaningless.
D. CHAPTER SUMMARY
It has been the purpose of this chapter to acquaint the reader with the
background of the computer security problem. This problem has been aggravated
by a general lack of understanding as to the true nature of the computer
security problem by those responsible for its solution. This has led to a
reliance on inadequate internal mechanisms, and false assurances as to their
effectiveness. It is important to understand this background because it serves
as a backdrop with which to view the subject of computer subversion, the
principal topic of this thesis.
[pp. 27-39]
There are three methods of attacking internal system controls in computers.
They are by inadvertent disclosure, penetration, and subversion. Each method
is briefly discussed. Later chapters will develop the details involved in
penetration and subversion. Distinctions are made between the current concept
of penetration and the concept of subversion.
A. INADVERTENT DISCLOSURE
Inadvertent or accidental disclosures are basically probabilistic in nature.
They may involve a combination of human, hardware, and timing factors that
when combined could allow a disclosure of information to an unauthorized
user. Simple examples of this method are a computer operator inadvertently
mounting the wrong tape, or the hardware failure of memory bounds checking
mechanisms. Users receiving information from this kind of disclosure are
often victims of circumstances and may not be malicious in their intent.
However, even though the success of this method relies on probabilistic events
that one cannot control, it can be utilized by the determined attacker.
The basic approach used by an attacker in this method is to sit and wait
for the proper set of circumstances to occur. Upon detection of a breach
in the protection mechanism, the attacker would take appropriate actions
to exploit the breach.
This method was addressed in the Multics Security Evaluation [10]. A program
called the "subverter" was written to run in the background of an unprivileged
interactive process. Once each minute the subverter program received a timer
interrupt and performed one test from a group of functions that would sample
the integrity of the security sensitive hardware. These tests included:
1. Testing master mode instructions.
2. Attempting to violate read and write permission on segment access control
lists.
3. Testing of all instructions marked illegal.
4. Taking out-of-bounds faults on zero length segments.
Methods similar to those above could prove profitable to a malicious user,
particularly if the system under attack had a history of questionable hardware
reliability. Although this method is a viable attack method, other methods
will be discussed that do not rely on these probabilistic circumstances.
B. PENETRATION
There are three major characteristics to penetration:
1. The penetrator is deliberate in his attempts.
2. The penetrator uses system foibles to circumvent system controls.
3. The methods are repeatable under the control of the penetrator.
It is important to realize that the penetrator is deliberate in his attempts.
This is because it introduces a class of "user" that contemporary computer
system designers had not seriously considered. Designs reflect that the systems
are expected to operate in a "benign environment" where violations of the
system controls are presumed to be accidental [2]. Because systems are presumed
to be in a benign environment, the attacker does not have to exert much effort
in his penetration attempts.
The second characteristic involves the utilization of system "foibles." Lackey
[11] defines the term:
A foible is an accidental or unintentional opening that permits unauthorized
control of the system or unauthorized access to information. It can occur
in either hardware or software, but software penetrations are more common.
A system programmer may inadvertently allow an obscure condition to occur
for which no check is made, or accept parameters without adequate checking.
Often the programs pass acceptance tests that don't expose these anomalies,
and the program will work properly when used as intended.
Foibles that can be used by a penetrator to circumvent system controls come
about because most computer designs for both software and hardware consider
efficiency and convenience as primary factors rather than security.
The method is repeatable because the foible is a part of the system design
or implementation. The penetrator can use it as though it were a "special
feature" of the system.
1. Penetration Environment
The penetrator carries out his malicious activities by using the computing
(or rather the penetration) environment as is. That is, he is content to
exploit the system using those foibles that the designers and implementors
inadvertently provided. But since deliberate penetration utilizes system
weaknesses or foibles, the penetrator may have his "access" routes cut off
if the fallibility is discovered by a legitimate user or system maintenance
personnel. However as indicated by Lackey, since the error was not detected
during testing and the system works properly when used properly, this appears
to be an effective method for gaining unauthorized information.
This is supported by reviewing the literature concerning computer crimes.
Many of the criminals were not caught by the discovery of their penetration
method or even in the actual act, but by some foolish action on the part
of the criminal after the fact (e.g., high living on embezzled funds). Only
through subsequent investigations did the foibles become known to the victims.
But this environment, although lucrative, is not under the "control" of the
penetrator. Foibles could be discovered and corrected or procedural deficiencies
revised. The determined penetrator would undoubtedly desire an environment
that is more under his control and not as susceptible to change and possible
detection by external forces.
2. The Penetrator
Current conceptions of computer system penetrators as glamorized by the
newspapers and other popular literature would have one believe the the penetrator
is a highly technical individual such as a programmer or computer scientist.
This is a misconception. Several studies have shown that the a more accurate
conception of the average penetrator is that:
1. He possesses only a limited technical knowledge of the computer system
[12].
2. He is a "white collar amateur" [13].
3. He is a user of the system, not the professional that supports the system
[12].
4. He lacks the ability to think big [14].
But all these conceptions of the known penetrator reflect the same thing:
that these conclusions are based on on the amateur that got caught. They
say nothing about the malicious elements that were sophisticated enough to
avoid detection. It is this group that poses the greatest danger to the security
of computer systems. What is the nature of the penetrator that was rot caught,
and how might he proceed in his malicious endeavors? It is imperative that
these questions be addressed.
C. SUBVERSION
Recall from chapter I that subversion of a computer system involves the covert
and methodical undermining of internal and external computer system controls
to allow unauthorized and undetected access to computer system resources
and/or information. But to understand the real implications of this definition,
further amplification is required.
Subversion is characterized by the following:
1. It can occur at any time in the life cycle of a computer system.
2. It is under the control of highly skilled individuals.
3. It utilizes clandestine mechanisms called artifices deliberately constructed
and inserted into a computer system to circumvent normal control or protection
features.
Each of these characteristics will be introduced in the following sections.
The detailed methodologies of subversion are discussed in the next chapter.
1. Subversion Over a System Life Cycle
Subversion is not limited to on-site operations, as in the ease of deliberate
penetration. It includes activities that spread over the entire life cycle
of a computer system. This life cycle includes several phases:
1. Design - The beginnings of a system. All key decisions concerning the
software and hardware specifications are made during this phase.
2. Implementation - The conversion of the design into a usable product. This
includes manufacturing and testing of hardware components, and the coding
and testing of software components.
3. Distribution - After all system components have been produced and tested,
they are distributed to the various operational sites.
4. Installation - Upon receipt of new system components, these components
must be installed and made operational. These components might be new software
on old equipment, or old software on new equipment, or any combination of
the above.
5. Production - This is the operational phase of the computer system and
is the phase that has traditionally received the most security considerations.
This consideration is because of the presence of the sensitive information
that is the object of the subverter's efforts.
The legitimate activities that are carried on during the various life cycle
phases offer ample opportunities for the subverter to undermine system
components. The activities in the first four phases are basically not sensitive
in nature and are carried out at relatively open facilities. Therefore, the
subverter would have little difficulty in subverting the system components
under development. Later in the production phase, these same components would
be involved in the protection of information. By this phase the subverter
would have an "environment" purposefully constructed for the unauthorized
and undetected exploitation of a system and the information it contains.
The next chapter will outline possible activities that can be carried on
by a subverter during each of these life cycle phases.
2. Skills Required
The subverter, unlike the penetrator, is not an amateur. To be able to carry
out subversive operations, the subverter must understand the activities that
are performed during the various phases of a computer system's life cycle.
But none of these activities are beyond the skill range of the average
undergraduate computer science major. In fact, much of the activity involved
with subversion can be carried out by individuals of much less technical
knowledge. Subversion can be particularly effective as an organized effort
that need only be CONTROLLED by the technically qualified.
The subverter, unlike the penetrator, does not lack the ability to think
big. He can utilize a diverse group of individuals that may or may not be
aware of the subversive activities they are performing. One need only imagine
the vast number of people that will have access to the various computer system
components prior to their being delivered to the control of an unsuspecting
ADP security officer.
3. The Artifice
The subverter could, and undoubtedly would, use various methods to circumvent
the control features of a computer system, including the foible that is
indicative of the penetrator's environment. But the subverter is concerned
with the long term return on his subversive efforts. To rely on a design
oversight or an implementation flaw that might be eventually corrected would
not be a sound "business" practice. Rather the subverter constructs his own
mechanisms that are inserted into the hardware or software during one of
the various phases of a computer systems life cycle. Any clandestine mechanism
that is used in subversion is called an "artifice" [11]. These mechanisms
can be implemented in either hardware or software. The most common forms
of artifices are known as trap doors and Trojan horses. A hardware artifice
is a particular instance of a trap door.
a. Trap Doors
The key characteristics of a trap door are:
1. It is exercised under the direct control of an activation stimulus.
2. It circumvents the normal control features of a system.
As the name implies, trap doors have a means of activation (like the latch
on a door). This activation key is under the direct control of the attacker.
A simple example of an activation key is a special sequence of characters
that is typed into a terminal. A software trap door program, embedded in
the operating system code, can recognize this key and allow the user of the
terminal special privileges. This is done by the software circumventing the
normal control features of the system. It is important to realize that the
only purpose of a trap door is to bypass internal controls. It is up to the
attacker to determine how this circumvention of control can be utilized.
The attacker can construct the trap door in such a manner as to make it virtually
undetectable to even suspecting investigators. A penetration tiger team,
organized by the Air Force to test the security features of a computer
manufacturer's operating system, installed a small trap door that was so
undetectable that the manufacturers personnel could not find the clandestine
code, even when they were told it existed and how it worked [6].
b. Trojan Horses
A Trojan horse is different from a trap door in several ways. Whereas the
trap door is generally constructed to circumvent normal system controls,
the Trojan horse can accomplish its malicious tasks without circumventing
these controls. Trojan horses are artifices, generally programs, that have
two functions:
1. An overt function - This function serves as a lure to attract the program
into use by an unsuspecting user.
2. A covert function - This function performs clandestine activities unknown
to the user of the Trojan horse.
The overt or "lure" function of a Trojan horse can, for example, be mathematical
library routines, word processing programs, compilers or any program that
might be widely used at an installation. Because these programs are executing
on behalf of the user they assume all access privileges that the user has.
This allows the covert function access to any information that is available
to the user.
The covert function is exercised concurrently with the lure function. An
example of this kind of artifice might be a text editor program that legitimately
performs editing functions for the unsuspecting user while browsing through
his directories looking for interesting files to copy. This is a particularly
effective option for the attacker due to the fact that as far as any internal
protection mechanism of the computer system is concerned there is no "illegal"
action in progress. The Trojan horse (e.g., text editor) is simply a user
program, executing in user address space, accessing user files, performing
perfectly legitimate system service requests such as giving another user
(e.g., the subverter) a copy of his files.
D. CHAPTER SUMMARY
This chapter has offered a brief discussion of the three methods that can
be used to attack a computer system. They are: inadvertent disclosure,
penetration, subversion. There have been important distinctions made between
the present conception of the known penetrator and his methods, and that
of the subverter and his methods. The known penetrator is basically an amateur
that is content to operate within the computing environment as it exists.
The penetrator's environment is one made of unintentional imperfections that
can be used to exploit a system. The subverter, on the other hand, is a
professional that actively constructs his subversion environment by the
methodical undermining of a computer system throughout its life cycle by
the use of artifices. The next chapter will discuss in greater detail the
methodologies of this subversion.
[pp. 40-93]
To reiterate the definition of subversion. it is the covert and methodical
undermining of internal and external security controls over a computer system's
lifetime to allow unauthorized and undetected access to system resources
and/or information. This chapter describes the methodologies involved in
subversion.
It has been the purpose of the previous chapters to "set the stage" for the
discussion that follows. It is obvious that there is not a clear understanding
in the computer security arena as to exactly what should be done to insure
that computer systems can reliably protect information. As long as this confusion
persists subversion will be a threat to the security of computerized information.
It should be kept in mind that those who might be involved in subversive
activities would not be confused as to what their goals are or how they would
accomplish them.
A. GENERAL CONSIDERATIONS
The majority of this chapter is concerned with the activities that a subverter
might consider as "field operations." These operations involve activities
that are required to insert artifices, exercise them, and retrieve the resultant
information. But there are several general considerations that should be
kept in mind when reading about the various phases of subversion. Principal
among these is that any reference to the subverter is meant as a reference
to the subversive organization. Individuals who might perform subversive
acts would do so with the guidance of all the expertise that might be available
in this organization.
1. Safe Computing Sites
Like any effective field operation, the subverter needs to insure that any
techniques and mechanisms used in the field have been perfected at a safe
computing site. This might seem difficult if a new system is the subversive
target. However, there are machines available today that are micro-programmable
emulators such as the Burroughs D Machine or the Nondata QM-1. A Feasibility
Study [15] has demonstrated that a very sophisticated, large scale computer
system (Multics) could be emulated on such a device. Because these machines
are micro-programmable, one machine can be used to support several field
operations.
Once a basic architecture is emulated, existing operating systems and subsystems
could be installed. These systems could then be analyzed for exploitable
foibles, and artifices could be designed and tested. The basic algorithms
for software artifices can be refined in a safe atmosphere to insure that
there are no unwanted side effects. Sound software engineering practices
would be employed to analyze the best approach to the subversion process.
2. Scope of Operations
The scope of subversion is completely under the control of the subverter.
It can be as focused as one computing site or as widespread as several hundred
installations, all with roughly the same expenditure of effort. This is
accomplished by selecting the phase of a computer systems life cycle in which
to start subversion operations [10]. The earlier in the life cycle a system
has been subverted, the more global the opportunities for exploitation.
By installing artifices at the beginning phases of the life cycle (design
or implementation) they will then become an integral part of the computer
system. Anyone who subsequently procures one of these systems will become
a potential target for exploitation. Identification of the victims need not
occur until later. Should the subverter not have the opportunity to begin
his operations in these first life cycle phases, he would have ample
opportunities in the later phases.
The subverter can narrow the scope of his operations by performing his malicious
activities during the distribution of system components to the selected sites.
He can select which sites are the most profitable and then intercept system
components as necessary to accomplish his goals.
Finally, by initiating subversion operations during the installation or
production phase of a computer system, he restricts his activities to that
particular site.
3. Desirable Traits in Artifices
The following discussion will center on the three major types of artifices;
software trap doors, Trojan horses, and hardware mechanisms. Not only are
the below listed traits desirable, but they are qualities that can be easily
incorporated into artifice construction.
a. Software Trap Doors
Recall that the principal function of a trap door is to circumvent internal
system controls under the control of an activation key. With this in mind,
the following are several desirable traits that the subverter would incorporate
in the implementation of this type of artifice.
(1) Compactness. To give the user of the trap door unauthorized privileges
may involve only enough code to recognize the activation trigger and the
one or two instructions required to change the machine state to master mode.
The fewer the instructions the better. Once this is accomplished, other programs
can be invoked to perform the desired clandestine activities.
(2) Revision independence. To insure that a trap door remains in the
system for years, perhaps its entire life, it is necessary to install it
in an area of code that will not be liable to revision. Operating system
software, as pointed out earlier, is often riddled with design errors or
subject to planned changes. Placement of the trap door should be in an area
that is not likely to undergo review. For example, I/O routines that are
used to control hardware devices are not generally changed in software revisions.
These are generally written in lower level languages for efficiency and offer
an excellent "refuge" for artifices.
(3) Installation independence. Many off the shelf general purpose
computer systems come with a wide range of options. But for a given family
of systems, there is usually a core operating system that will be common
to any installation within the system family. By installing the trap door
in this "core" of code the subverter is assured that his artifice will be
present in the system regardless of the particular configuration that would
be generated at the installation.
(4) Untraceable. The operation of the trap door should not in itself
leave any trace of its operation. This implies that either its operation
does not encounter system traps or audit trails, or it has the ability to
erase any evidence of its activities. Frequently, the very "primitive" or
basic functions of an operating system, such as a teletype stream handler,
are at too low a level to be audited in system logs. These routines are also
relatively "stable" in that they are generally not subject to frequent revision.
(5) Uniquely Triggerable. The means by which the trap door is activated
should be unique enough to insure that accidental activation is unlikely.
One example is a trap door that is triggered by a unique sequence of characters
in a teletype stream. Too short a sequence or too common a sequence might
accidentally activate the artifice by someone other than the subverter or
his agent. On the other hand, to long a sequence might require to much code
to check against and make the trap door code too long.
(6) Adaptability. The trap door should have a degree of generality
or even programmability. Since the trap door might have been installed during
the early phases of the systems life cycle, the subverter cannot always predict
the particularities of the installation or application. For instance, since
trap doors circumvent normal controls, it could be designed to modify operating
system code online. By circumventing the write protection of the operating
system code area the trap door can allow the subverter to adapt the operating
system to his needs.
b. Trojan Horses
As previously stated, a Trojan horse is a program that is invoked by an
unsuspecting user. It will perform a legitimate function (the lure) and a
covert function. The following are a few desirable traits for this artifice.
(1) Directed Lure. The lure (or overt) function of the Trojan horse
will determine what kind of information will come under the scrutinization
of the covert function. If the desired information is scientific in nature
then it might seem plausible to construct a Trojan horse that offers a lure
of some sort of mathematical computation. If personnel records are the target
then the lure might be a sort routine. It should be noted that the information
available to the Trojan horse is any information that would be normally be
available to the unsuspecting user. Not just the information needed to perform
the lure function. This is because most operating systems consider any program
executed by a user to be "owned" by that user for the duration of the program
execution. Any access rights that the user might have are imparted to programs
run on his behalf.
(2) Compatibility of Functions. The covert and overt functions of
a Trojan horse should perform "expected" actions. It is not expected that
a mathematical library routine would access the users file space (e.g., the
covert function browsing through files) when it is computing the roots of
a polynomial. System audit logs may record this activity and suspicions be
aroused. This could be disastrous if the covert function was to inadvertently
cause the user process to be interrupted by a disk error. However it is expected
that a sort file routine will access the user's file space. Subsequent disk
errors might be overlooked as merely a fluke. This can be viewed as way to
"functionally disguise" the Trojan horse.
c. Hardware Mechanisms
A hardware mechanism is a special instance of a trap door. It performs the
same function of circumventing normal system controls as its software
counterpart. Its capabilities and traits are essentially the same. The method
of activation may vary due to the unique hardware capabilities such as the
ability to transceive radio signals. There are two cases of hardware mechanisms,
programmable and non-programmable. Examples of each of these types are presented
later in the chapter.
4. Obscuring Artifices
Proper obscuring can make artifices virtually undetectable. One must realize
that once code or hardware is operational in a computer system there would
be no reason to review it unless something failed. Think of how hard it is
to find a difficult bug that is being purposefully searched for in a program.
One can imagine how difficult a small trap door would be to find if the author
of the trap door takes special pains to obscure it. Furthermore, even if
found, the well-designed artifice will appear to be just another bug. Obscuring
artifices is considered essential to the subversion process. Obscuring techniques
are limited only by the ability and understanding of the subverter installing
the artifice.
Listed below are a few techniques that the subverter might use in this process.
a. Modifying Object code
Binary machine code is the most obscure medium in which a software artifice
can reside. The Multics Security Evaluation [10] amplifies this point:
Clearly when a trap door is inserted, it must be well hidden to avoid detection
by system maintenance personnel. Trap doors can best be hidden in changes
to the binary code of a compiled routine. Such a change is completely invisible
on system listings and can be detected only by comparing bit by bit the object
code and the compiler listing.
Disadvantages of this obscuring method come about because object modules
may be periodically recompiled for various reasons [10]. This, of course,
may not be under the control of the subverter and methods must be devised
to insure periodic reinsertion. It has been informally reported [10] that
a compiler could be "enhanced" to always reinsert an artifice in the object
code when a particular system module was recompiled. Compilers themselves
are rarely recompiled by the user. So the clandestine code that was located
in the compiler would be quite safe.
Obscuring in object code is particularly suited for Trojan horses. Software
that is procured from vendors as "off the shelf" computing aids often do
not provide source code listings. This is to protect proprietary rights.
The subverter (perhaps a legitimate vendor) can use this fact to his advantage.
He could offer software products to unsuspecting computer installations much
as any other software vendor might. In fact, the subverter could anticipate
the installation's needs if he had agents on the premises that knew the
particular situation. Since the subverter is not primarily in the business
of making money by selling software, he can undercut competitive bids.
Detection risks for this obscuring method are considered relatively low.
Even if the Trojan horse were to malfunction and lead system maintenance
personnel to suspect it of "performing strangely," without source code
documentation the first order of business would be to contact the vendor
for another copy of the program.
b. Abusing of Software Engineering Practices
When using source code as a means of inserting artifices, means must be devised
to obscure the true purpose of the clandestine code. Program documentation
could prove invaluable in this effort. Good program documentation is essential
to the understanding of complex programs such as operating system software.
Most higher level languages allow variable names of ample length. Yet many
programmers are content to follow archaic FORTRAN or assembler-like practices
that tend toward short, abbreviated variable names that have meaning only
to the programmer at the time he wrote the code. Inadequate commenting of
source code is another common abuse.
Writing programs that are unstructured or non-modular in organization can
prove quite effective for obscuring. This is commonly refered to as "spaghetti
bowl" logic. By using non-local "goto" statements that seem to jump around
the program arbitrarily, it is virtually impossible to follow the program
logic.
Allegedly "good" documentation practices can also be utilized in the obscuring
process. This technique can simply be labeled as lying. Plenty of apparently
good comments can lure the reader away from scrutinizing the code too closely.
Mislabeled variables can also steer the reader away from the actual purpose
of the clandestine code.
The use of source code as a mean of inserting artifices has the dual distinction
of offering the subverter the greatest returns as well as the greatest risk
of detection. Source code artifices will not be destroyed by recompilation
of the code as some other methods of insertion. However because it is in
human readable form, artifices are more visible and therefore more vulnerable
to possible detection [10].
c. Using Assembler languages
Most assembler language traits both good and bad are beneficial from the
subversion standpoint. Some of these traits are:
1. Most "powerful" language available.
2. Most efficient in execution time and core requirements.
3. Least comprehensible of all the human interpretable computer languages.
Assembler languages are the most "powerful" because they allow greater control
over the programming environment than any other language. Assembler languages
are not constrained to the addressing restrictions that are imposed by the
structured environments of the higher level languages. There is no distinction
between data and code areas. This allows the subverter to either write
self-modifying code or obscure clandestine code as data. Assembler programs
are noted for their "spaghetti bowl" logic because it is difficult to write
assembler programs that do not use goto statements. Since goto statements
are expected in assembler code, it is easy for a subverter to write a program
that has a goto statement whose operand is a variable label rather than a
statement label. The variable label could define the beginning of a series
of hexadecimal or binary constants that are nothing more than the equivalent
binary opcodes of the clandestine routine. Close scrutiny is rarely given
to these "tables" of constants, particularly if the program is functioning
properly.
Assembler language source code is assembled to machine code instructions
on an almost one-to-one basis. Therefore the subverter can exactly predict
the amount of "overhead" the artifice will impart to the subverted system.
d. Strategic Placement
Obscuring software artifices, particularly trap doors can be greatly enhanced
by strategically placing the clandestine code away from areas that might
be subject to investigation. For example, consider a trap door that is triggered
by an activation key from a teletype. Perhaps security investigators suspect
that a trap door exists and that it is activated by a teletype stream. Naturally
the investigation would inspect all code that handles the teletype stream.
The subverter can foil these efforts by placing the trap door in an area
totally unrelated to the teletype routines, such as the disk I/O driver.
Since the trap door resides in a routine that executes in the master mode,
addressing restrictions do not apply, and the teletype buffer is addressable
from the trap door's vantage point.
The subverter can either wait for normal disk usage or execute a "do nothing"
program that uses the disk. This will insure that the trap door that resides
in the disk driver routine will be exercised at the same time the activation
key is present in the teletype buffer area. Upon recognizing the activation
key the trap door will perform the necessary task required to circumvent
the normal controls.
e. Using Confinement Channels
Confinement channel is the general term applied to information paths that
can exist between a program (called a service) and its owner. The information
is gained when another program (called a customer) invokes the service and
the service subsequently extracts unauthorized information from the customer
and passes it to the owner of the service [16].
Much of the computer security evaluation criteria [8] mentioned in Chapter
II is concerned with what is called the simple security condition. This condition
states that a subject (user or his program) cannot have read access to objects
for which he is not cleared. Confinement channels generally meet this condition.
However they do not meet what is called the confinement property (also known
as the *-property). The confinement property states that if one program has
read access to data at one security level it cannot have write access to
another file at a lower security level [21]. Thus the program is "confined"
to not, in effect "declassify" information, but it is confined to write into
a file of the same security level or higher.
Most systems do not even consider the issues of confinement. If an artifice
was to introduce such a channel it would probably not be recognized for what
it was. One type of this channel is sometimes called a covert channel. This
channel is called covert because the method by which the information is passed
is particularly difficult to detect. An example is offered by Denning [14]:
One type of flow cannot be controlled easily, if at all. A program can convey
information to an observer by encoding it into some physical phenomenon without
storing it into the memory of the computer. These are called flows on covert
channels... A simple covert channel is the running time of a program.
Because these channels for information flow are not the normal paths that
information are thought to flow on (i.e., variable parameters, files and
other "storage channels") they are easily overlooked by investigators. In
the simple example above Denning [14] explains how the running time of the
program can be used to convey information:
A program might read a confidential value, then enter a loop that repeatedly
subtracts 1 from the value until it reaches zero. The owner can determine
the confidential value by simply observing the running time.
Confinement channels will be discussed again in later sections of the chapter.
f. Hardware Obscuring
Today integrated circuit technology offers a near perfect medium in which
to obscure hardware mechanisms. Equipments that have medium scale integration
(MSI) chips can be replaced with enhanced large scale integration (LSI) chips.
The enhanced chips would perform the required functions of the original chips,
but also perform functions under the control of the subverter. Detection
of these devices, once installed in target equipment is virtually impossible,
since the subverter would undoubtedly insure that all external appearances
such as physical appearance, logical operation, power consumption, etc.,
would be the same. There is no non-destructive way to thoroughly examine
these devices.
B. INSERTING ARTIFICES OVER THE LIFE CYCLE OF A COMPUTER SYSTEM
The subverter by inserting artifices into a computer system is, in effect,
"creating" a subversion environment on the targeted computer system. He is
inserting the "tools" which he will use to undermine the security of a computer
system. Once this security is subverted, he can then extract the information
he desires. But the timeframe between when the artifice is inserted and when
information is retrieved may be years.
Be can be very successful in his insertion efforts because the places in
which the subversion occurs, are relatively open environments that are not
hardened against his efforts. This is because there maybe no classified
operations being conducted at many of the places the subversion occurs.
There is an interesting property in the insertion activity that differs from
most other forms of criminal activity. The subverter is not removing or stealing
anything from the premises, on the contrary, he is introducing "a little
something extra."
1. Design Phase
The subversion of a computer system design is a subtle process. As in any
design process there are hundreds of alternatives to consider. Among the
many choices on any given issue, several may prove acceptable. It is the
job of the subverter to be the "standard bearer" of those alternatives that
will aid him in his subversion efforts.
Inadequate design choices have been used in the past to exploit a system.
In 1974 the Naval Research laboratory conducted a penetration exercise on
a Univac 1108 system running under Exec VIII. The author of the resulting
report [17] comments:
However, even if an MLS (multilevel security system) is completely bug-free,
in the sense that its response to user requests is completely specified by
its design, this does not imply that the MLS will not permit dissemination
of data to unauthorized users. Our penetration of Exec VIII is not based
on bugs in the implementation, though they certainly exist. Instead, we exploit
several aspects of the Exec VIII design philosophy which, when taken together,
make penetration possible.
Details of this particular penetration exercise are outlined later in the
chapter.
The following is a brief discussion of how the subverter might make seemingly
sound design choices and still subvert a systems design.
a. Operating System Software
(1) Password procedures. There are several ways to design password
login procedures. Three viable choices that the subverter might propose are:
1. encrypt the passwords with a seemingly non-invertable algorithm
2. allow the user to choose his own passwords
3. allow multiple login attempts for the "forgetful" user.
The first case was used on the Multics system at the time of the USAF security
evaluation [18]. The designers of the system hoped that the algorithm they
were using was non-invertable, the evaluation demonstrated that it was not.
In the second case, user chosen passwords are often easy to guess [10]. One
such system allowed the user to choose his own password. The system
administrators would enter a new user into the password tile and as a
convenience, would enter the user's name as his password until the user's
first session, at which time the user was supposed to change the password
to one of his own choosing. Due to a design choice, the password file was
readable by all users. This in itself was not a cause for alarm, as the password
field is encrypted. But the first entry in the file is the user's name in
plain text. A malicious user, knowing the administrator's procedure, attempted
the login sequence using the names in the password file until there was a
successful login (presumably from a new user). Subsequent investigations
revealed that many of the users had not ever bothered to change their passwords.
This also points out the problem of allowing too many login attempts.
(2) Audit Procedures. Two design suggestions that a subverter might
recommend are:
1. audit all actions that might be security related (the more the better),
or
2. audit only user mode actions.
The subverter by recommending excessive auditing will, in effect, render
the auditing process ineffective. Those that are tasked with the manual reviewing
of audit logs will be quickly buried by the sheer volume of it all. The listings
will quickly fall into disuse in the corner of some storeroom.
By auditing only user actions the subverter is given free "license" to implant
his artifices in master mode routines that are "trusted." The subverter need
not worry about any actions carried out by artifices that exist in master
mode routines because their actions will not be traced by any audit mechanism.
If a trap door circumvents control of the system by placing the subverter
in master mode then any subsequent actions of the subverter will not be audited.
(3) Confinement Channels. Some areas of the computer system could
be designed to pass information via a confinement channel. Should the subverter
find himself working in one of these areas he would undoubtedly take advantage
of the opportunity. The concept can be best illustrated using an example.
Many operating system designs are process oriented. Each time a new process
is required by the system, a unique identifier is assigned to this process
so the system can keep track of all the different processes. There appears
to be nothing significant about the process-id. Therefore it would seem
irrelevant as to how this unique identifier is selected. Logically the easiest
choice would seem to be to assign process-id numbers sequentially as they
are needed. By making this design choice the subverter has constructed a
confinement channel.
Assume there are two processes, "A" and "B," active in a system at the same
time. Process "A" is a clandestine service routine (with a Trojan horse)
that has access to sensitive information. Process "A" desires to communicate
some of this sensitive information to process "B," that is not authorized
access to the information. They will communicate by using the process-id
number as a binary communication channel. Because process-id numbers are
assigned sequentially, process "B" can deduce information from the id number
based on the previous values. If "A" desires to send a binary "1," "A" will
create two new dummy processes (and immediately destroy them). This will
increase the Process-id number by two. If "A" desires to send a binary "0,"
it will create and destroy one process.
On the receiving end, "B" will create one process and save the id-number
and then destroy the process. "B" will compare the new process-id with the
one saved from its last active period and compare the two. If it is three
greater than the previous process-id the information sent was a "1" , if
it was two greater it was a "0." Because both "A" and "B" are executing on
the same machine, these activities are not occurring at the same exact time
and they are synchronized (in a crude sense). Because there will be other
processes in the system creating new process-id numbers, the channel will
be "noisy." But modern information theory can be applied to detect transmission
errors and reliable results can be obtained [16].
(4) Backward compatible features. Manufacturers must insure that new
product lines are backward compatible if they wish to upgrade old customers.
The subverter can capitalize on these design requirements by insuring that
older system foibles are carried along to the new systems design. The IBM
Systems Journal [19] offers an example:
Two VM/370 features were discovered that permitted a total penetration, and
others were discovered that could cause the system to fail. The first case
concerned the OS/360 use of self modifying channel programs in its ISAM access
method. To support this feature in a virtual machine, VM/370 had been modified
to examine channel programs for the pattern associated with the use of
self-modifying code by OS/360. The VM/370 method of handling such channel
programs was to execute some commands out of the user's virtual storage,
that is, not in VM/370 virtual storage space. As a consequence, a penetrator,
mimicking the OS/360 channel program, could modify the commands in his storage
before they were executed by the channel, and, thereby, overwrite arbitrary
portions of VM/370.
b. Other Software Design Choices
Most computer systems are offered with a suit of supporting software such
as compilers, text editors, service routines, etc. These can provide the
subverter opportunities to incorporate Trojan horses into the overall system
design. Software that is supplied as part of a package deal is financially
attractive to customers that would have to otherwise procure these items
from other sources. Many times for efficiency or convenience, a service like
a compiler will have special privileges (like executing in master mode for
some functions). Thus a trap door in this program is as effective as one
in the operating system itself.
Service routines that are designed for benign purposes can be used by the
subverter to insert artifices. IBM/360 offered one such service [20]:
The means for inserting a penetration mechanism into an existing program
(either system or user) stored on a direct access device is provided by one
of the Operating System/360's own Service Aid programs, IMASZAP. This program
is designed to modify data and instructions at any given location on a direct
access file, which is to say, one can modify information anywhere on a disk
pack.
c. Hardware Alternatives
The selection of hardware for computer systems will also offer the subverter
many opportunities to aid his cause. The subverter can concentrate on central
processors, peripheral equipments, or both.
(1) Central Processors. The selection of central processors from the
subverter's point of view is straightforward. The simpler the architecture
the less effort that will be required to subvert it. Optimally the best choice
is an architecture with no hardware protection mechanisms. But this choice
is an impractical one for both the subverter as well as the customer. There
would be little chance that such an architecture would be considered for
use in a system handling sensitive information, ard the subversion effort
would be for naught. The subverter must work within at least minimum guidelines.
For example, one set of minimal guidelines can be found in The ADP Security
Manual [8]. This list of mechanisms is extensive. One would think that
such a complete list is sufficient to assure a secure system. However, many
of the penetrated systems in Chapter II had these features and penetrators
were very successful in their efforts. It is important to realize that having
these features is not sufficient for a secure condition, it is how effectively
they are employed. It is the job of the subverter to ensure that they are
not effective even if they are present. The following is from The ADP
Security Manual [8]:
4-200 Hardware Features.
a. The execution state of a processor should include one or more variables,
i.e., protection state variables, which determine the interpretation of
instructions executed by the processor...
b. The ability of a processor to access locations in memory (hereafter to
include primary and auxiliary memory, should be controlled (e.g., in user
mode, a memory access control register might allow access only to memory
locations allocated to the user by the O/S).
c. The operation of certain instructions should depend on the protection
state of the processor. For example, instructions which perform input or
output operations would execute only when in master mode. Any attempt to
execute an instruction which is not authorized should result in a hardware
interrupt...
d. All possible operation codes, with all possible tags or modifiers, whether
legal or not, should produce known responses by the computer.
e. All registers should be capable of protecting their contents by error
detection or redundancy checks...
f. Any register which can be loaded by the operating system should also be
storable, so as to permit the O/S to check its current contents against its
presumed contents...
g. Error detection should be performed on each fetch cycle of an instruction
and its operant (e.g., parity check and address bounds check).
h. Error detection (e.g., parity checks) and memory bounds checking should
be performed on transfers of data between memory and storage devices or
terminals.
i. Automatic programmed interrupt should function to control system and operator
malfunction.
j. The identity of remote terminals for input or output should be a feature
of hardware in combination with the operating system.
k. Read, write, and execute access rights of the user should be verified
on each fetch cycle of an instruction and its operant.
These requirements as outlined in the Security Manual are general
enough so that viable arguments can be constructed to demonstrate most major
vendor's processors "acceptable." A way in which the subverter could meet
the letter of these requirements and still defeat the protection mechanisms
was demonstrated in the Multics Security Evaluation [10].
The vulnerability involved violation of requirement "k" listed above (access
on each fetch). The Security Manual states that each instruction must
produce known results (requirement "d" ), but this vulnerability involved
a SEQUENCE of instructions. The Multics Security Evaluation [10] outlines
the method:
This vulnerability occurred when the execute instruction was in certain
restricted locations of a segment with at least read-execute (re) permission.
(see figure 1) The execute instruction then referenced an object instruction
in word zero of a second segment with at least R (read) permission. The object
instruction indirected through an ITS pointer in the first segment to access
a word for reading or writing in a third segment. If all these conditions
were met precisely, the access control fields in the SDW (segment descriptor
word) of the third segment would be ignored and the object instruction permitted
to complete without access checks.
This particular hardware "bug" resulted from a field installed design change
to the equipment that was installed at all the computing sites. A subverter
might well include such features in the initial hardware design.
Figure 1. Execute Instruction Bypass
(2) Peripherals. Generally, peripherals do not have the stringent
requirements placed on their internal behavior like central processors. They
are generally thought of as being under the control of the central processor
and if the CPU is "contained" (in a security sense) then the peripherals
will follow. This concept is rapidly changing in today's technology. Many
devices such as direct memory access (DMA) I/O equipments are specialized
processors in their own right.
Configuring a system so that "specially modified" I/O devices can intercept
(or directly access) sensitive information is totally within the realm of
the subversive designer. Likewise, procurement policies that are based on
the lowest bidder can (and have been known to) result in a composite system
that comes from a variety of manufacturers. A subversive designer can specify
equipments to such a degree that only one vendor (the subverter) will be
able to meet the specification. By specifying in this manner or by competitive
pricing these "enhanced" equipments can find their way into a "secure" computer
system.
2. Implementation Phase
In this phase of a computer system's life cycle, there are two computer systems
to consider. There is the computer system under development, and there is
the computer system used for the development the the "host" computer). The
subverter would first penetrate the host computer. Once this is accomplished,
he would have access to the new software under development. This technique
was demonstrated during the Multics Evaluation [10]. A trap door was inserted
into a new version of the Multics software that was to be distributed to
all Multics sites.
The target, of course, would be the new software (or hardware) under development.
It would be these new products that would be employed in the protection of
information in the future.
Inserting artifices during the implementation phase can offer as many advantages
as inserting during design. In fact, there are additional advantages because
inserting artifices during implementation of a system does not require the
subverter to be on the vendor's payroll.
Often programmers can work from their homes on remote dial-up terminals.
Because these vendor development systems are not hardened against wiretapping
or other possible penetration techniques, the subverter can infiltrate as
desired. Private corporations would tend to shy away from particularly
restrictive security practices when there is no classified activities present.
The Multics Security Evaluation [ 10] which was written in 1974 pointed out
such an environment:
... it should be noted that the software for WWMCCS (World Wide Military
Command and Control System) is currently developed using uncleared personnel
on a relatively open time sharing system at Honeywell's plant in Phoenix,
Arizona. The software is monitored and distributed from an open time sharing
system at the Joint Technical Support Agency (JTSA) at Reston, Virginia.
Both of these sites are potentially vulnerable to penetration and trap door
insertion.
Two areas of activity that might be subject to subversion in the implementation
phase are, coding and testing, and hardware assembly and checkout.
a. Coding and Testing
Coding and testing of system software is concerned with one major goal: that
the programs perform at least the required functions. This is a minimal
requirement, not a maximal one. Testing criteria involves only insuring that
a given module performs the required tasks correctly. It does not involve
the concept of determining all the functions that it might be able to perform.
In general, this characteristic cannot be determined for a program since
this reduces to the unsolvable safety problem [4] discussed earlier.
If subversive activities are to be carried out by the actual programmers
assigned to the project, there are a few general practices that the subverter
might follow. One such practice is using global or external attributes for
variables that might not otherwise require them. This can make data available
to other covert routines that will be able to utilize them. This is common
practice in operating system programming, particularly if the language used
is assembler language.
Some languages, particularly higher level languages that are constructed
for operating system use, do not perform run time bounds checking on data
structures that use subscripting or pointers. This is not done because the
extra code required cannot be afforded in an operating system environment.
Effective use of such structures can allow clandestine routines access to
areas that would be otherwise inaccessible. For instance, a routine that
has a trap door installed performs some processing on an array that is passed
to it. The maximum expected size might be 100 elements. If there is no runtime
subscript bounds checking, the routine could check the area Just beyond the
100th element for a unique bit pattern that would activate the trap door.
Specific features such as hardware bounds checking mechanisms will not help
much because there would be no violation of the job's total address space.
b. Hardware Assembly and Checkout
The safest time to carry out subversion activities on hardware is during
the assembly of the equipment. Insertion costs and detection risks would
be low during this period. Equipment could be assembled with specially enhanced
integrated circuits that appear and function exactly like the normal circuits.
This could be done by intercepting the supplier's shipment of parts to the
assembly plant and replacing them with the subverted hardware. This way the
subverter would be totally removed from the insertion process. Entire product
lines can be equipped with these hardware trap doors. If shipments could
not be intercepted, or if the assembly plant was the manufacturing facility
as well, other arrangements could be made. Assembly line personnel could
replace the normal chips in the assembly line parts bins with the enhanced
chips. Plant security is typically oriented toward individuals taking products
out of a plant, not bringing them into it.
3. Distribution Phase
The most significant advantage to inserting artifices in system components
(hardware and software) during the distribution phase is that the subversion
occurs after the review process is completed. These components already carry
the "seal of approval" and will, in all probability, not be subjected to
close scrutiny again.
Subversion activities carried out during the distribution phase require
significantly less investment in technical talent than than other phases
of the life cycle. Activities involve the replacement or modification of
valid equipments and software with subverted copies. Personnel who might
be involved are delivery truck drivers, mailmen, receiving or shipping clerks.
Most of these personnel can perform their aspect of the subversion and not
be aware of the "big picture." Even if apprehended and interrogated their
knowledge of the extent of the operation would be minimal.
Suppose that the subversive organization legitimately purchased several terminals
from a company. Upon receiving these terminals they are carefully unpacked
so as to not damage the original shipping containers. Technicians could then
modify the terminals with special "enhancements" and insure that they perform
as desired. The terminals are then carefully repacked so that nothing would
appear disturbed. When the subverters received word that company XYZ had
ordered some of these same terminals for a new multilevel security application,
they could be replaced for the normal terminals. This way the subverters
have a steady supply of terminals, with only the initial investment.
There are various methods that could be employed to substitute the enhanced
terminals for the normal ones. It might require the services of a slightly
dishonest truck driver or warehouse clerk.
The important point is that the terminals would not be suspected because
they were not "stolen" in the classical sense of the term, just replaced
with "enhanced" versions. The shipping papers could be changed to reflect
the different numbers if serial numbers could not be changed.
In other areas, the process might even be easier. Companies often put out
advance notice of upcoming software revisions, or hardware field changes.
Subverters could be alert to these things and be ready with enhanced revisions
or field changes. On a software revision the subverter could conceivably
intercept a software revision tape and modify (or replace it) within hours,
The delay would be negligible.
Another method that can be used is for the subverter to generate bogus software
revisions or field changes to be carried out by system maintenance personnel.
These changes can be forwarded with forged stationary and customers would
have no reason to suspect that the changes are bogus [10].
4. Installation Phase
The installation of any computer system is a rather chaotic period. The subverter
can capitalize on this chaos and use it to his advantage.
There are several opportunities to install software artifices during the
initial installation of a new system, particularly a new operating system.
Several bugs are bound to surface and the system may require numerous
regenerations of code to test out all the changes required by the tailoring
of the system to the particular installation.
Systems programmers will be uncertain about the new systems behavior patterns.
In such an uncertain environment security personnel will naturally not allow
sensitive information to be processed, and in fact might allow the system
to be run under less control than would otherwise be present. It is doubtful
that a malicious systems programmer would be scrutinized very closely and
he could insert many trap doors into the new system.
Many decisions are made during these initial break-in periods concerning
operational procedures that the subverter can offer his "advice" on. Each
installation is different and requires judgment calls on the particular situation
at hand. A highly technical subverter (such as the vendor's representative)
can prove surprisingly effective in this kind of situation.
An interesting method for inserting trap doors that can be implemented during
the installation phase is suggested in the Multics Security Evaluation [10].
Here, the system initialization code is modified by the penetrator to insert
other trap doors as the system is brought up. Such trap doors can be relatively
invulnerable to detection and recompilation, because system initialization
is usually a very complex and poorly understood procedure.
5. Production Phase
Inserting artifices during the production phase of a system's life cycle
may entail more risk than inserting during the other phases. All security
measures will be in place due to the presence of sensitive information. But
these risks are only high in comparison to inserting during the other life
cycle phases, and in an absolute sense can be quite acceptable. Recall that
the common "computer criminal" or penetrator works exclusively in this
penetration environment and has had excellent results. Techniques used by
the subverter to install artifices in the production phase of a system are
the same techniques used by the penetrator to generally exploit a system,
i.e., system foibles.
One could argue that it seems senseless to use an unintentional trap door
(a foible) to install an intentional trap door (an artifice). But one must
remember that the subverter is not out for the "quick dollar." He is a
professional that is in the business of gathering information over a long
period of time. The subverter will certainly use any device at his disposal,
but the deliberate, well thought out, and tested artifice can insure results
over the long haul, with a minimum of risk. The artifice will continue to
work even if the original foible is found and corrected.
It is instructive to examine how one might insert clandestine code in a system
when it is in an operational or production mode. The example chosen is the
Univac 1108 penetration exercise. The success of the exercise was due to
two design foibles [17]:
1. Inadequate error recovery. For any given job the user had the ability
to request the control of error recovery. In general an error routine in
the Exec VIII operating system had access to the same addressing environment
as the routine causing the error. Exec VIII did not stack error handling
routine requests, but deleted the previous request.
2. Unprotected reentrant routines. Shareable non-executive reentrant routines
in Exec VIII are called reentrant processors (REP). Examples of these are
compilers, text editors, data management subsystems, etc. Each REP must have
an associated data area that is writable. Due to a hardware design oversight,
write protection is provided for BOTH instruction and data banks or for neither.
For the REP to be able to modify its associated data bank the code area must
run unprotected from modification.
Due to Exec VIII core allocation policies, there was usually a number of
unused words at the end of the last core block allocated to the REP code
area. The sequence of events was as follows [17]:
1. A legitimate program called BREAKER requests to handle its own error recovery.
2. The BREAKER program prepared an out-of-bounds data bank for the victim
REP and linked to it.
3. BREAKER invoked the victim REP and the REP immediately caused a guard
mode error while trying to access its data bank.
4. Control was immediately returned to the BREAKER routine via the error
handling request. BREAKER then had write access to the victim REP.
5. BREAKER checked the end of the victim REP to see if there were enough
free words in the code block to insert a calling sequence to a clandestine
routine. If there was, the entry point of the REP was changed to a jump to
the beginning of the free area and a calling sequence was inserted in the
free area.
Using this method a subverter could essentially build a general purpose Trojan
horse that could be used in various ways. Depending on the purpose of the
clandestine program invoked by the calling sequence, the subverter could:
1. access information owned by any user who subsequently invokes the victim
REP.
2. install trap doors in programs owned by users of the victim REP, such
as the operating system.
6. Summary
The insertion phase is the most significant aspect of the subversion process.
The efforts that go into this phase yield tools that will give the subverter
access to information almost as easily as the owner of the information. Whereas
the subverter has constructed a sound foundation from which to work, he has
left the legitimate user one of sand.
C. EXERCISING ARTIFICES
The discussion up to this point has centered on the subverter creating the
subversion environment. Attention will now turn to how the subverter can
use this environment to exploit a computer system. There are several activities
that can be carried out by the subverter after he has activated the artifice
[11]:
1. extraction -- the withdrawal or copying of data
2. alteration -- changing or modification of data, programs or hardware,
3. addition -- adding extraneous data
4. utilization -- using the system resources maliciously.
All these activities are possible objectives of the subverter. Before these
activities are discussed it is instructive to first understand how the artifices
that will enable these activities are triggered.
1. Activating Artifices
a. Software Activation
(1) Trojan Horses. Trojan horses are usually activated by the victim
program. Although the mechanism is considered activated that does not imply
that the covert function of the Trojan horse will necessarily do anything
malicious. Due the the possible wide usage that a Trojan horse can get, the
subverter may desire to limit the information that it gathers.
A text editor can be enhanced to check the file name of those files it is
employed to edit and based on a predetermined target the Trojan horse will
respond accordingly. The target might be the system password file. When the
editor senses this file it will copy the file to a safe place, otherwise
it will lay dormant. A safe place is any area that is accessible to the
subverter. This may be a file in the subverters own directory or a system
buffer area that is accessible via a clandestine routine.
(2) Trap doors. Should the subverter require close control over when
an artifice is activated, it might require an agent to input the trigger
via a terminal or by submission of a batch job. The activator need not be
aware of what clandestine activities are in progress. For instance, suppose
a trap door was inserted in a system during the implementation phase of the
systems life cycle. The subverter knew exactly what tasks needed to be performed
but not when. Remember that the insertion may have taken place years prior
to the time of its activation. Imagine the following scenario.
A janitor is in the process of cleaning a room that contains a terminal.
Like many installations the system runs 24 hours a day. The janitor has received
instructions to turn on the terminal and type in a given string of characters.
He then proceeds with his cleaning chores. At the end of a predetermined
time the janitor switches off the terminal, and proceeds as though nothing
had happened. The trap door was programmed to periodically check the teletype
buffer for the predetermined pattern, perform its clandestine function and
then erase all traces of its actions.
Another method of activation for trap doors is by timer. If a subverter is
aware that some valuable information will be input into the system after
a certain date, he can install a trap door that will periodically check the
system clock for a certain date. Upon recognizing that the date has occurred
the trap door will copy the information to a safe area for later retrieval.
Variations on this theme have been informally reported within the Department
of Defense. These artifices were implanted by disgruntled employees. The
results of these implantations can be disastrous. It could mean the voiding
of thousands of dollars worth of software because there is no way to find
the malicious code and the risk could too great. If such a mechanism was
installed in something like automated process control software, thousands
of dollars worth of damage could result.
b. Hardware Activation
Methods for activating hardware artifices will vary with the sophistication
of the mechanism. The following are a few examples:
1. An enhanced chip that is part of a teletype terminal is activated by the
system's login sequence. Upon recognizing the sequence, the chip will store
the user's name and password in the chip's own memory area.
2. An "intelligent" chip such as a special purpose microprocessor that can
be microprogrammed by the data stream that follows the trigger. This mechanism
could reside in peripheral equipment and be used to selectively copy data
to other storage devices on command.
3. A central processor that has been "modified" to disable memory checking
mechanisms or place the processor in master mode when a special sequence
of unused opcodes is executed. The opcodes when executed in any other order
will have no effect on the processor. There would be another special sequence
of code that would restore the processor to normal operation.
2. Techniques of Exploitation
After the artifices have been activated there are several activities in which
the subverter can engage. Below is a brief discussion of some of the
possibilities.
a. Breaking Out of a Subsystem
As pointed out earlier, subsystems are built around an underlying operating
system. This subsystem will use the primitive operations of the operating
system to construct the restricted environment that the user will see. To
the operating system (and the subverter) the subsystem is nothing more than
another program running concurrently on the system.
Assume a subsystem is designed to restrict the user to performing simple
calculator functions. That is, the user can type simple mathematical expressions
at the terminal and the answer will be typed in reply. Any input other than
a valid expression will result in the subsystem replying with the message
"invalid expression, try again." This is clearly a restricted environment.
The user does not have the ability to execute programs, or use any of the
other services offered unrestricted users.
But if the underlying operating system had been subjected to subversion,
the subsystem could be easily bypassed by the user. The method that can be
used is similar to the trap door used by the janitor.
The user activates the trap door by typing in the trigger sequence. The trap
door is periodically scanning the teletype buffer area for the trigger sequence.
When the sequence is recognized by the trap door the terminal is removed
from the subsystem environment and given whatever control the subverter that
inserted the clandestine code desires.
b. NPS Penetration Case
During the time that this research was being carried out, one of the schools
computer systems was subjected to "attack" by a malicious individual. The
system in question was a PDP-11/50 running under the UNIX operating system.
This case is a simple example of breaking out of a subsystem.
The subsystem under consideration was the "games" monitor. This system has
several games programs that came with the system or were written by students
as class projects. The subsystem is "constructed" by having users (no password
required) that log in under the games user-id restricted to executing only
those programs and commands that reside in the games directory. The games
option is only enabled during off processing periods when the system use
is low. The malicious user was familiar enough with the system to know the
dial-up terminal phone number. It was apparent that he was familiar with
the UNIX system, because he wrote a program (the trap door) and inserted
it into the games directory.
The program was called "ZX" and it was a "C" language program that executed
one command language (called "shell") statement. Since this program was in
the games directory, the monitor environment did not prevent the execution
of the command language statement. This trap door gave the individual all
the privileges of an unrestricted (non-super) user. He could (and did) read
the password file for names of legitimate users. He found some users that
had the same password as their name (this example was mentioned earlier).
He was later discovered logged in under some of the legitimate users' names,
or would respond with one of these names when queried online.
Dial-up capabilities were eventually restricted by a monitor to specially
authorized personnel, and the mysterious "attacker" did not make his presence
known again. Several procedural errors where identified in the course of
the investigation and have since been corrected. Among these were the password
assignment procedures (mentioned earlier) were no longer initialized as the
user's name, and the restriction of the dial-up capabilities. This "attacker"
did not appear to be malevolent in his actions. He seemed as though he was
looking for a little "free" computer time. But there is no way to determine
this for sure, nor is there a way to determine what other artifices might
still be present in the system.
c. Using Emitters
Computer systems are electromagnetic emitters like any other piece of electrical
equipment. Information can be gathered by monitoring these emanations.
Communication lines and cathode ray tubes are particularly vulnerable to
these techniques [11]. Security personnel are generally aware of this problem
[8]. Computer sites can be measured for the amount of emanations present.
If they are sufficiently low, a site could be certified as satisfactory in
this area. However, if there were covert transceivers embedded in the equipments
at the factory this "certification" could prove useless. A transceiver that
is monitoring a data bus could sense a data stream trigger. Upon activation
the transceiver would begin to broadcast the activity on the data bus at
a higher power level than would be normally present. Since the transceiver
was not active during the "certification" its presence would not be detected.
A similar sequence could act as the deactivation key to stop the transceiver
from broadcasting. As one can see this is nothing more than a specialized
hardware trap door.
d. Memory residue
In a resource shared system the allocation of memory could result in the
exposure of sensitive information to unauthorized users. Unless specific
actions are taken by the operating system or the previous user, memory assigned
to a new user program will contain whatever was last placed in it.
The ADP Security Manual [8] addresses the problem:
The O/S shall ensure that classified material or critical elements of the
system do not remain as accessible residue in memory or on on-line storage
devices.
This means that the operating system must clear core before it is assigned
to a program. This mechanism, if subverted, could be designed to "turn off"
by command.
This could prove valuable to the subverter who has agents that are legitimate
users of a system. As a matter of standard procedure the agents could perform
the following actions whenever they are processing jobs:
1. program begins execution and immediately turns off the clear core mechanism
by activating an artifice.
2. program waits for sufficient residue to build up in the free core area,
and requests additional core for the next processing step.
3. upon receiving the additional core the program dumps the contents of the
core to a file in his directory for later review.
4. program turns residue mechanism back on and completes legitimate tasks.
Another problem with memory residue arises when a computer is involved in
what is commonly called "periods processing." A periods processing environment
is one that uses the same computer to process information of different security
levels, but at different times.
After each processing period in one mode, special procedures are carried
out to insure that all traces of information are removed from the system.
This is known as "color changing." This includes removing all tapes, cards,
printouts, ribbons, etc., from the system. The next shift would bring all
the necessary equipment with them to do the same. One of these procedures
is, of course, clearing core. The program used to "clear" core could be one
that writes random patterns into core. This could be be repeated several
times to ensure a good "brainwashing." Assuming the color change was from
classified to unclassified, it would be possible to obtain information from
the previous processing period. If the program that cleared core did not
write random patterns into core, but just encrypted the information, it would
be undetectable by the operator. A clandestine process, that runs in the
unclassified period could core dump the information to files for later
decryption.
e. Using Confinement Channels
Confinement channels have traditionally been thought of as a slow means of
extracting information. But in an environment where particular care has been
taken to defend against subversion, this method may be the only way of gaining
information. Channels on the order of a bit per second have been demonstrated
and channels that can pass on the order of tens of bits per second have been
hypothesized [22]. The following are a few examples of what form these channels
might take:
1. If the system has interlocks which prevent files from being opened for
writing and reading at the same time, the the service can leak data if it
is merely allowed to read files that have been written by its owner. The
interlocks allow a file to simulate a shared boolean variable which one program
can set and the other can test[16].
2. By varying its ratio of computing to input/output or its paging rate,
the service can transmit information which a concurrently running process
can receive by observing the performance of the system. The communication
channel thus established is a noisy one, but the techniques of information
theory can be used to devise an encoding which will allow the information
to get through reliably no matter how small the effects of the service on
system performance are, provided they are not zero. The data rate of this
channel may be very low, of course [16].
3. An exploitable path for information flow can be created between an uncleared
individual accessing the system during one processing period and the classified
information processed by the system during another processing period if,
over time, the same software is employed in both processing periods. Such
a "covert leakage path" can effectively negate the necessary complete isolation
between processing periods...[23].
Case 1 is very similar to the process-id binary channel discussed earlier.
But in this case the binary channel is the interlock. The owner (subverter)
knows the service program (which has access to the sensitive data) is sending
a binary "1" if the service opens the given file for reading. This is because
he should be prevented from writing into the file by the interlock. He would
be receiving a "0" if he was permitted to write the file.
Case 2 is similar to the example that measured the runtime of a program.
In this case low system performance means a "0" and higher system performance
a "1."
Case 3 is an example of passing information between processing periods. Assume
that the machine in question is one that supports memory paging. Also assume
that the programs in question are reentrant routines. This means that they
would not get swapped out during a page fault, just overwritten. Should the
program be able to execute in the master mode, it could write sensitive
information into unused portions of the code block (like the UNIVAC 1128
example). Since the code block was modified the page swapping routine would
swap it out vice overwriting it. When the next unclassified processing period
starts, the subverter merely reads the data from the code block of the program.
f. Affecting System Performance
Not all subversion activities would be concerned with gathering information.
For some computer systems the subverter may only be interested in rendering
these systems ineffective at key times. Tactical or strategic systems are
examples of where this might be desirable.
A systems design or implementation could be subverted so that its performance
may suffer during critical situations. It is often difficult to test such
systems under critical real world conditions. These systems could meet
performance specifications under simulated situations but prove ineffective
in a real world situation.
Triggering of artifices in these systems can be by external events. Suppose
there is a command and control system that keeps track of potentially hostile
ships. A trap door entered during the implementation phase of this particular
system is designed to activate whenever it detects that a certain ship was
reported at a certain position. When the opposing side decides to start hostile
operations, it could send the designated ship out to the predetermined position
before the start of hostilities. The ship could remain at that position long
enough to insure that the intelligence system had time to enter the ship
into the system. When the trap door recognized the activation key (ship
identification and position) it could cause the system to gradually degrade
in performance until it was ineffective. The ship would have, in effect,
"sunk" the command and control system from thousands of miles away. Examples
of what an artifice could cause to happen to this kind of system are:
1. cause the system to crash at random intervals,
2. slow down the system performance by randomly clearing core page usage
data, thus causing the system to swap pages in and out of core excessively
(thrashing),
3. randomly ignore or lock out the command console.
Activity such as this would render the system unreliable and create an
unwillingness to use it. Furthermore, systems maintenance personnel would
make the system unavailable for many long hours while looking for a bug that
may never be found. Since it was installed during the implementation phase
it would exist in all copies of the system code.
D. RETRIEVING INFORMATION
Once information has been accessed by the methods outlined previously, the
problem of removing the information from the confines of the security perimeter
still remain. As one might expect, the difficulty of the retrieving process
is directly related to the "strength" of the security perimeter. In a relatively
open system retrieval might be as easy as walking out the front door with
listings under one's arm. In a more restrictive environment other methods
can be devised. In a multilevel security mode, the unclassified user is
frequently not scrutinized; in fact, he might by using a dial-up terminal
several miles from the computer installation.
This discussion will assume that the exercising phase of subversion has placed
the desired information in a "safe" place (i.e., any area that is accessible
to the subverter).
1. Retrieving Files
If the internal protection mechanisms were used to enforce the security perimeter
(as in a multilevel security system) then the subverter may have a simple
job of retrieving the information. Since the security controls were circumvented
in obtaining the information, the security perimeter has been breached and
retrieval may only involve dumping the information out in some transportable
form. However, if this is not the case the information may be reviewed by
someone before it is allowed to cross the security perimeter. In this case
the information must be disguised or perhaps even encrypted.
Information can be hidden in the heater pages or system job statistics areas
of batch job printouts. These are often ignored areas of a listing. These
areas could offer low bandwidth channels for the information.
Encrypting information into statistical tables or core dumps can significantly
increase the volume of information that can be channeled through the security
perimeter.
2. Retrieving with Hardware devices
Hardware transmitters can be used to pass information beyond the security
perimeter. These devices can offer channels of very high bandwidth. A high
speed printer that had a transmitter embedded into it during the installation
phase is an example. Again the activation key could be a sequence of characters
in the data stream that turns on the transmitter and a similar sequence to
turn it off.
An interesting method that could be used for a low bandwidth channel is the
front panel of the computer console. Some installations have big glass windows
that define an external security perimeter. A subverter could submit an
unclassified job to a system that could serve to activate a trap door. The
subverter only need watch the register lights for the information to be flashed
to him. Naturally the normal register lights would be flashing too rapidly
for the subverter to understand them. However the parity light for the registers
could be controlled in such a manner that they could send Morse code to the
subverter. By having a program that repeatedly enters even parity or odd
parity values in to a register an information channel could established.
Furthermore, the flashing could be recorded photographically or using video
tape.
E. CHAPTER SUMMARY
This chapter has outlined the methodologies of computer subversion. This
subversion may involve the organized efforts of many individuals whose talents
could range from a computer scientist to an unskilled laborer. Subversion
is a three step process involving the insertion of artifices into computer
system components, exercising them, and retrieving the resultant information.
The insertion process could be carried out over the entire life cycle of
a computer system, from the beginnings of its design through to, and including,
the the production phase. Once installed these artifices can be used to
circumvent normal internal controls of the computer system for the purpose
of accessing unauthorized information. Once unauthorized access is obtained,
the subverter need only disguise this information into a form that will
circumvent any external controls that may exist, thus effecting its retrieval.
Subversion is clearly a threat to the security of any information that relies
on a computer system to protect it. In the next chapter ways of minimizing
the risk of subversion are investigated.
[pp-94-105]
Theoretically, there are three ways in which subversion can be minimized,
and they relate directly to the three phases of subversion:
1. Prevent the the insertion of all mechanisms that can be utilized to defeat
internal security controls, or
2. Prevent the malicious user from exercising these mechanisms, or
3. Prevent the retrieval of any information gained via exercising techniques.
Any one of the three methods mentioned above could prevent subversion. Each
method will be briefly discussed as to its merits in helping to minimize
the threat of subversion.
A. RESTRICTING INSERTION OPPORTUNITIES
Preventing the subverter from inserting artifices may not be a simple task,
but it is essential to the ultimate solution to the problem of subversion.
It has been demonstrated how subversion can occur over the entire life cycle
of a computer system. To prevent the insertion of artifices implies that
the subverter must be prevented the opportunity to access system components
at any point during this life cycle. Clearly, system components that affect
the security of the system must be afforded lifetime protection.
1. Lifetime Protection
For lifetime protection to be effective it must involve such measures as:
1. Appropriate security clearances for any personnel involved in the various
stages of the computer systems life cycle [2].
2. Sufficient "hardening" of manufacturing and development programming sites
to prevent subversion by external forces [2].
3. Proper protection of all system components from access by malicious elements
for the entire system's life cycle.
Without the above measures, proper assurances would not exist concerning
the safe history of system components. That is, whether or not malicious
elements have had the opportunity to subvert the components. The only appropriate
course of action would be to not allow these components to participate in
the protection of information. This is because the very nature of subversion
is covert, and it would be virtually impossible to detect if it had occurred
in a system after the fact. If any period during the lifetime of a computer
system has a lapse in protection it must be similarly assumed that these
components are unreliable from that point forward.
2. Appropriate Protection Policies
The above measures should be viewed in the proper perspective. What is meant
by "sufficient hardening" of development sites, or "proper protection" of
system components?
Just because a computer system will be involved in the protection of classified
information does not mean that the system components are themselves inherently
classified. It would therefore not be appropriate (even counterproductive)
to demand that these system components be protected in the same way as classified
materials. For instance there would not be any reason to prevent copies of
programs from being seen. The central issue is not the content of the programs,
but restricting access (for modification) to the particular copies of those
programs that will be used to enforce protection in the system.
A more appropriate protection policy is needed. In essence this policy should
outline a strategy of "look, but do not touch." For instance, in the area
of development or manufacturing sites, hardening does not have to be concerned
with emanations where there is no sensitive information contained in the
operating system code or hardware equipment at this point in the life cycle.
Similarly, the proper protection of system components would dictate that
they be protected from malicious elements having access. Previous chapters
have outlined in detail that there are many ways that a subverter can access
system components. Therefore, countermeasures to these access routes must
be devised. But restricted access need only apply to those particular programs
and equipments actually involved in the protection of information. Copies
of the programs could conceivably be made available to anyone. However, those
particular components (programs or hardware) that will actually be used in
the protection of information need to be clearly distinguished and protected.
Specifically, those particular components involved in the protection of
information should be labeled and protected from access at the same level
as the information they are expected to protect.
One of the basic principals of subversion involves the introduction of
clandestine mechanisms into security related system components. However current
DOD security program regulations and directives [7, 8, 24] are primarily
concerned with the REMOVAL of sensitive materials from a secure environment.
These directives must be changed to ensure that security not be compromised
by the INTRODUCTION of materials as well.
B. RESTRICTING EXERCISING OPPORTUNITIES
To prevent the exercising of mechanisms that could defeat internal system
controls, one could:
1. Find and eliminate all such mechanisms, or
2. Somehow guarantee that they could not be employed.
Both these "solutions" when applied to current operating systems are, in
any practical sense, infeasible. Both these solutions assume that such mechanisms
can be identified in the first place. To do do this would require a means
of determining that every program executed on a machine is "safe." But chapter
II brought out the fact that there is no general solution to the safety problem
[4]. A simple example of this is a Trojan horse. As previously indicated,
the user willingly invokes a malicious program and, in doing so, gives it
"permission" to perform its covert functions. Not only will most computer
systems not prevent the employment of such a program, it will unknowingly
aid in its endeavors.
Finally, one must consider the system foible (design and implementation errors).
Recall that these are mechanisms that can also be of use to the subverter.
To presume that all such foibles are identified and eliminated is to imply
that the perfect design was flawlessly implemented. This is a highly unlikely
prospect. Chapter II offered ample testimony to the fact that current technology
is a long way from the perfect implementation of something the size of a
modern operating system. If "accidents" such as system foibles are difficult
to find, then the deliberately obscured artifice would be virtually impossible
to detect. Attempting to prevent the exercising of artifices is a futile
approach.
C. RESTRICTING THE RETRIEVAL OF INFORMATION
Restricting the retrieval of information must presently be considered the
last defense against subversion. This is obvious because, as pointed out
earlier:
1. No assurances exist as to the absence of past subversive activities on
system components, therefore subversion of the components must be assured.
2. There exists no general method that can prevent the exercising of clandestine
mechanisms in a computer system.
Ultimately, preventing the retrieval of unauthorized information from a system
will lie with the effectiveness of the security perimeter. If the subverter
can cross this defensive barrier then he has, in effect, retrieved the
information. One must clearly delineate where this perimeter lies. Unless
it is clearly delineated, one cannot determine the effectiveness of those
mechanisms designated to enforce it.
1. Delineating the Internal Security Perimeter
When the security perimeter of a computer system is enforced by strictly
external means, the system is said to be operating in the dedicated security
mode [21, 22]. The security perimeter is clearly defined as those physical
measures (such as guards, etc.) required to insure that no unauthorized
information will leave the boundaries of the perimeter. All users, equipment,
and information reside within this perimeter. The effectiveness of this kind
of security perimeter is easily determined as it is based on established
practices that are not unique to computer security. The dedicated mode of
operation is the result of the need to restrict retrieval of information.
This is certainly a sound technique but it does not solve the classical computer
security problem. That is, the need to reliably share information of varying
degrees of sensitivity among users of varying degrees of trustworthiness.
In the case of the computer that is used in the multilevel security (MLS)
mode, the security perimeter is less clear. In this mode of operation the
security perimeter is enforced by the internal protection mechanisms of the
computer system. This is because personnel that are not cleared for the highest
level of information contained within the system are allowed some form of
access to the system. The only barrier between the uncleared user and the
information that he is not authorized to access is the internal protection
mechanisms of the computer system. Therefore it is imperative that this internal
barrier (i.e., security perimeter) be well defined within the system.
The difficultly with contemporary computer systems is that control of these
internal protection mechanisms is distributed throughout the entire operating
system. There is no clear distinction as to which parts of the system enforce
the security perimeter and which do not. As a result of this vagueness, any
attempt to evaluate the effectiveness of a computer system to enforce a security
perimeter is doomed to the ad hoc approaches such as those outlined in Chapter
II. And these are notoriously ineffective.
So called "trusted" subsystems compound the problem by attempting to "establish"
a security perimeter with a special program. But ultimately a subsystem will
use the very same protection mechanism that the underlying operating system
uses. It should be clear by now, that in the face of subversion the subsystem
is not the least bit more secure than the underlying operating system and
other security related components that it embraces.
It is clearly essential that any internal protection mechanism be defined
in such a way that it's effectiveness can be demonstrated. One such mechanism
is the Security Kernel. Schell [6] states:
The chief distinguishing characteristic (from whence its name) of the security
kernel concept is that a kernel represents a distinct internal security
perimeter. In particular, that portion of the system responsible for maintaining
internal security is reduced from essentially the entire computer to principally
the kernel.
It is instructive to see how this mechanism could be used to prevent the
subverter from retrieving unauthorized information.
2. Security Kernel Concept
In a system that is based on a security kernel, protection is realized within
the computer system by the verifiable implementation of a mathematical model
of information security. This model is based on an abstract representation
of security called the reference monitor [5]. The reference monitor describes
a mechanism for controlling the access privileges within the system (see
references [2, 5] for further details on the monitor). The implementation
of this mechanism is the security kernel.
The security kernel is designed to be a verifiable subset of security related
operating system functions. These functions form an interface (i.e., a security
perimeter) between the user and the information. If the security kernel is
implemented correctly, its use will guarantee that the information in the
system will be protected in accordance with the security policy that is outlined
in the security model. Essential design requirements of the security kernel
are:
1. It must be tamper proof.
2. It must always be invoked.
3. It must be small enough to be subject to analysis and tests, the completeness
of which can be assured.
The Multics Security Evaluation [10] points out how contemporary systems
have been unable to meet these criteria:
The stated design goals of contemporary systems such as GCOS or OS/360 are
to meet the first requirement (albeit unsuccessfully). The second requirement
is generally not met by contemporary systems since they usually include
"bypasses" to permit special software to operate or must suspend the reference
monitor to provide addressability for the operating system in exercising
its service functions. The best known of these is the bypass in OS/360 for
the IBM supplied service aid, IMASPZAP (SUPERZAP). Finally and most important,
current operating systems are so large, so complex, and so monolithic that
one cannot begin to attempt a formal proof of certification of their correct
implementation.
Two basic precepts that are enforced in the security kernel are:
1. The simple security condition - this means that a user or his program
is not allowed access to information for which he has no authorization.
2. Confinement property - if a user or his program has read access to information
at one security level, say secret, then he cannot have simultaneous write
access to a file that exists at a lower security level (i.e., unclassified).
This prevents what is called a "write down."
These simple precepts and other supporting strict rules of the security kernel
are the basis by which the subverter is prevented from retrieving unauthorized
information.
In the case of the Trojan horse, the simple security condition and the
confinement property can render such a clandestine mechanism useless. The
basic concept behind a Trojan horse presumes that it will be allowed into
an environment that contains sensitive information. Once in this environment
the covert function attempts to obtain sensitive information and place (write)
it in area that will be accessible to a subverter. The security kernel, through
the confinement property, will not permit a "write down." That is, it will
prevent the covert function from "declassifying" the information by not allowing
it to be copied to anywhere but another classified file. Assuring the subverter
is an unclassified user, the simple security condition will prevent him from
accessing any files gained through this method because he will not have the
proper clearance to to read the file provided by the Trojan horse.
D. CHAPTER SUMMARY
Security kernel technology directly addresses the problem of minimizing
subversion. It offers a basic design that can be proven effective. Through
this verifiable protection mechanism a distinct internal security perimeter
can be relied on to prevent the retrieval of unauthorized information by
malicious elements.
But security kernel technology is not immune to to the subversive techniques
outlined in this thesis. In fact, it might be more susceptible to subversion
due to the high probability that such a system will be used in sensitive
areas. Lifetime protection is essential to any mechanism that will be employed
in the protection of information.
The security kernel clearly defines the security related mechanism of a computer
system. Because of this it is the only part of a computer operating system
that need be offered lifetime protection. Providing protection for the security
kernel is a far more practical an idea than requiring the lifetime protection
of an entire operating system and numerous privileged utilities. Its small
size and clear boundaries offer a secure foundation from which to build any
operating system. But without lifetime protection from malicious access,
there would be no assurances as to the integrity of components involved in
the protection of information and subversion must be assumed.
[pp. 106-108]
This thesis offers a detailed examination of an aspect of the computer security
problem known as subversion. It is not the purpose of this document to provide
a handbook of subversion for subverters; they do not need one! This thesis
does offer awareness to those who must deal with the computer security problem.
People like ADP administrators, ADP security officers, system designers,
and others involved in the decision-making process must understand subversion
if they are to effectively combat it. It is difficult to make intelligent
decisions concerning the security of information in computer systems unless
one understands the possible extent of the vulnerabilities that could exist
in them.
The first part of this thesis identified several problem areas in computer
security. One of these areas involve a lack of a coherent policy concerning
the exact role that computers should play in the protection of information.
This in turn has led to a reliance on inadequate internal mechanisms, and
false assurances as to their effectiveness. All these problem areas play
a role in the success of subversion.
Important distinctions have been made between the current conception of computer
penetration and that of subversion. The penetrator is basically an amateur
that exploits system design and implementation errors to gain control of
a system. Subversion on the other hand involves the organized efforts of
several individuals, some of whom are highly competent at the subversion
process. The subversion process involves the use of clandestine mechanisms
called artifices. Principal among these artifices are trap doors and Trojan
horses. By constructing and inserting these mechanisms into computer systems
the subverter creates a safe environment which can be used to exploit a computer
system at will.
The three phases of subversion are the inserting of artifices, the exercising
of them, and the retrieval of the resultant unauthorized information. Central
to the theme of subversion is the insertion of artifices over the entire
life cycle of a computer system. This can be done because computer system
components that would be involved in the protection of information do not
receive adequate protection against subversive activities during their lifetimes.
Subversion is a clear threat to the security of any computer system involved
in the protection of information. This threat must be minimized before computer
systems can be relied on to adequately protect information. Until such a
time, no computer system should be used as a means to protect information.
So-called "trusted" subsystems are no exception. They suffer from the same
risk of subversion as any other system. The problem of "trusted" subsystems
is compounded by the fact that they are built on an underlying operating
system that is essentially unsecureable. These systems must be considered
particularly dangerous to use because they lull the user into a false sense
of security.
Minimizing the threat of subversion is a twofold process. First, adequate
lifetime protection must be afforded to all security related components that
will be involved in the protection of information. The integrity of security
related components cannot be assured without this protection.
Second, the application of adequate technology as exemplified by the security
kernel concept must be incorporated in the design of secure systems. Without
this verifiable design, the effectiveness of the protection mechanism cannot
be reliably determined. Unless these essential requirements are met, there
will be no such thing as a secure computing system.
[pp. 109-110]
1. "Consensus Report, Processors, Operating Systems and Nearby Peripherals,"
Theodore M. P. See (Chairman), AFIPS Conference Proceedings, 1979
National Computer Conference, June 4-7, 1979.
2. USAF Electronics Systems Division Report ESD-TR-73-51, Vol. I, Computer
Security Technology Planning Study, October 1972.
3. Gat, Isreal, "Security Aspects of Operating Systems," Second Jerusalem
Conference on Information Technology, 1974 .
4. Harrison, M.A. Ruzzo, W.L., Ullman, J.D., "Protection in Operating Systems,"
Communications of the ACM, Vol. 19, no. 8, August 1976.
5. Schell, Roger R., LtCol., USAF, "Security Kernels: A Methodical Design
of System Security ," USE Inc., Spring Conference, March 1979.
6. Schell, Roger R., LtCol., USAF, "Computer Security, The Achilles Heel
of the Electronic Air Force," Air University Review, Vol. XXX, no.
2, January-February 1979.
7. Department of Defense Directive 5200.28 "Security Requirements for Automatic
Data Processing (ADP) Systems," 19 December 1972.
8. Department of Defense Manual 5200.28M "Techniques and Procedures for
Implementing, Deactivating, Testing,and Evaluating Secure Resource-sharing
ADP Systems," January 1973.
9. Nibaldi, G.R., "Proposed Technical Evaluation Criteria For Trusted Computer
Systems," Mitre Corp., no. M79-225, Bedford, Mass., 25 October 1979.
10. USAF Electronics Systems Division Report ESD-TR-74-193. Vol. II, "Multics
Security Evaluation: Vulnerability Analysis," by Paul A. Kruger, 2Lt., USAF
and Roger R. Schell, Major, USAF, June 1974.
11. Lackey, R. D., "Penetration of Computer Systems, an Overview," Honeywell
Computer Journal, Vol. 8, no. 2 1974.
12. Comptroller General of the United States, Report to the Congress.
Computer Related Crimes in Federal Programs, General Accounting Office
(GAO), April 27, 1976.
13. Stanford Research Institute Report PB-231 320, Computer Abuse,
by Donn B. Parker, Susan B. Nycum, and Stephen S. Cura, November 1973.
14. Denning, Peter J. and Dorothy E. "Data Security," Computing Surveys,
Vol. II, no. 3, September 1979.
15. Rome Air Development Center Report RADC -TR-74-137, Emulating a Honeywell
6180 Computer System, Mitre Corporation, June 1974.
16. Lampson, D.W., "A Note on the Confinement Problem," Communications
of the ACM, Vol. 16, no. 10, October 1973.
17. Naval Research Laboratory Memorandum Report 2821 Subversion of a "Secure"
Operating System, by David Stryker ,June l974.
18. USAF Electronics Systems Division Report ESD-tR-74-193, Vol. III,
Multics Security Evaluation: Password and File Encryption Techniques,
by Lt. Peter J. Downey, USAF, June 1977.
19. Attanasio, C.R., Markstein, P.W., and Phillips, R.J., "Penetrating an
Operating System: A Study of VM/370 Integrity," IBM Systems Journal,
Vol. 15, no. 1, 1976.
20. Goheen, S.M., and Fiske, R.S., OS/360 Computer Security Penetration
Exercise, Mitre Corp., Bedford Mass., October 1972.
21. USAF Electronic Systems Division Report ESD-tR-75-69, The Design and
Specification of a Security Kernel for the PDP-11/45, by W.L. Schiller
(Mitre Corp)., May 1975.
22. Lipner, Steven, "A Comment on the Confinement Problem," Mitre Corporation,
Bedford, Mass.
23. Department of Defense Industrial Security Newsletter, no. 80L-1,
28 March 1980.
24. Department of Defense Information Security Program Regulation 5200.1R,
December 1978.
25. Information Sciences Institute Report ISI/SR-78-13, Protection Analysis:
Final Report, by Richard Bisbey and Dennis Hollingworth, May 1978.
[pp. 112-113]
No. Copies
1. Defense Technical Information Center 2
Cameron Station
Alexandria, Virginia 22314
2. Library, Code 0142 2
Naval Postgraduate School
Monterey, California 93940
3. LtCol. Roger R. Schell Code 52Sj 5
Department of Computer Science
Naval Postgraduate School
Monterey, California 93940
4. Asst. Prof. Douglas Smith Code 52Sc 1
Department of Computer Science
Naval Postgraduate School
Monterey, California 93940
5. Lt. Philip A. Myers, USN 5
Naval Data Automation Command
Washington Navy Yard
Washington, D.C. 20374
6. LCDR. S.L. Reitz 1
NAVAL SEA SYSTEMS COMMAND
Technical Representative
St. Paul, Minnesota 30945
7. Capt. L.A. Talmage 1
Manpower Utilization Unit
Building 2009
MCDEC, Quantico, Va. 22134
8. Capt. John Ross, USAF 1
552 AWACW/ADM
Tinker AFB, Oklahoma 73145
9. Ms. Cheron Vail, Code 302 1
NAVPERSRANDCEN
San Diego, California 92152
10. Lt. M.L. Maurer, USN 1
CARGRU Five
F.P.O. San Francisco, California 96601
11. Lt. W.J. Wasson, USN 1
Naval Electronics Systems Command
Headquarters, PME 124
Washington, D.C. 20360
12. Department Chairman, Code 52 2
Department of Computer Science
Naval Postgraduate School
Monterey, California 93940
13. Lt. Alan Gary, USN 1
Operations Department
U.S.S. Nimitz (CVN 68)
F.P.O. New York, New York 09542
14. LCDR. Edmund Moore, USN 1
Naval Electronics Systems Command
Headquarters, PME 107
Washington, D.C. 20360
15. Lt. William C. Hess, USN 1
Naval Electronics Systems Command
Headquarters
Washington, D.C. 20360
16. SCDR. B. Johnson, Code 0371 1
Computer Technology Curricular Office
Monterey, California 93940
17. Mr. Carl Landwehr 1
Code 7522
Naval Research Laboratory
Washington, D.C. 20375
Transcription and HTML by JYA/Urban
Deadline.
